Gas-electric hybrid ultra-long endurance inspection drone solution

In the fields of power inspection, forestry monitoring, border inspection and other fields, higher requirements are put forward for the endurance and inspection functions of drones. This solution takes gasoline-electric hybrid technology as the core, deeply optimizes the configuration of energy management and inspection systems, and creates a professional inspection drone suitable for long-distance and long-term operations to meet the needs of efficient inspections in complex scenarios.

1. High-efficiency petrol-electric hybrid power system

(1) Upgrading of petrol-electric hybrid architecture

use Intelligent series hybrid system , consisting of a high-power-density aviation heavy-fuel engine and a large-capacity, high-energy-density lithium battery pack. As the power generation unit, the engine is a 4-stroke turbocharged model with a maximum power of 150kW, which can continuously and stably generate electricity to charge the battery pack. ； As the power output unit, the lithium battery pack uses ternary lithium batteries with a capacity of 200Ah to ensure instantaneous high power output. Through the intelligent energy management system, the engine and battery pack work together. During the cruising phase, the engine generates electricity under optimal working conditions, and excess power is stored in the battery. ； Under acceleration, climbing and other working conditions, the battery pack provides auxiliary power to improve power performance.

(2) Power system energy saving optimization

  1. Efficient transmission design : Adopting a direct-drive transmission structure to reduce transmission components and energy loss, the transmission efficiency is increased to 92%. At the same time, the matching of motors and propellers is optimized, and a dedicated low-speed, high-torque motor is selected, paired with a large-diameter, low-speed propeller, to reduce air resistance during flight and improve propulsion efficiency.

  1. Intelligent power generation control : Real-time adjustment of engine speed and power generation based on flight status and battery power. When the battery power is higher than 80%, the engine automatically reduces the speed and enters low-power power generation mode. ； When the battery power is lower than 20%, the engine speed will be increased to increase power generation, giving priority to ensuring flight safety.

2. Super long battery life guarantee

(1) Energy system optimization

  1. Large capacity fuel storage : Designed with a streamlined built-in fuel tank with a capacity of 80L, combined with an efficient fuel management system, it can effectively improve fuel utilization and reduce fuel consumption. At the same time, a quick refueling interface is adopted to shorten refueling time and improve operating efficiency.

  1. Battery performance enhancement : Use a new generation of high-energy-density ternary lithium batteries with an energy density of 260Wh/kg, which is 30% higher than traditional lithium batteries. The battery pack has an intelligent thermal management system that uses liquid cooling and temperature balance control to ensure that the battery can maintain optimal working conditions under different ambient temperatures and extend battery life.

(2) Aerodynamic optimization design

  1. Large aspect ratio wing : Adopting a large aspect ratio glider wing design with a wingspan of 8 meters and a lift-to-drag ratio of 18, which effectively reduces flight resistance and reduces energy consumption. The wings are made of carbon fiber composite material to reduce their own weight while ensuring structural strength.

  1. Streamlined body : The fuselage is aerodynamically optimized and adopts a drop-shaped cross-section design to reduce air turbulence and reduce the drag coefficient. At the same time, the surface of the fuselage is smoothed to eliminate unnecessary bulges and gaps to further improve aerodynamic performance.

3. Professional inspection system configuration

(1) Multi-sensor fusion perception

  1. HD photoelectric pod : Equipped with a 30x optical zoom high-definition camera and an infrared thermal imager, the camera resolution reaches 4K, and the infrared thermal imager has a resolution of 640×512 pixels, which can clearly capture targets in day and night environments. Supports autofocus and image stabilization functions to ensure stable and clear shooting images.

  1. lidar system : Equipped with multi-line lidar, the scanning frequency reaches 20Hz, the scanning angle is 360°, and the detection distance is up to 200 meters. It can build a three-dimensional environment model in real time to achieve high-precision terrain mapping and obstacle detection.

  1. weather sensor : Integrate a variety of meteorological sensors such as temperature and humidity, air pressure, wind speed and direction, to monitor the meteorological conditions of the flight environment in real time, and provide data support for flight safety and inspection tasks.

(2) Intelligent inspection function

  1. Independent route planning : Through the ground control station or cloud platform, the optimal patrol route can be automatically generated based on the terrain and mission requirements of the patrol area. Supports waypoint editing, altitude setting, flight speed adjustment and other functions to meet patrol needs in different scenarios.

  1. Intelligent target recognition : Built-in AI image recognition algorithm, which can automatically identify damaged power line insulators, forest fire hazards, illegal buildings and other targets, and mark and upload location information in real time. At the same time, it supports custom target recognition models, and users can train specific target recognition algorithms according to actual needs.

  1. Real-time data transmission : Adopting dual links of 4G/5G communication and satellite communication to ensure that inspection data can be transmitted to the ground control center in real time and stably under different network environments. Supports the transmission of multiple types of data such as high-definition video streams, 3D map data, and inspection reports.

4. Application scenarios

  1. Electric power inspection : In the vast transmission line area, long-distance autonomous inspections can be carried out to quickly discover line faults and equipment hazards. Compared with traditional manual inspections, the efficiency is increased by more than 80%.

  1. forestry monitoring : Conduct long-term inspections of large areas of forest to promptly detect problems such as forest fires, pests and diseases, and provide strong support for forestry resource protection.

  1. border patrol : In border areas with complex terrain and harsh environment, long-term and large-scale patrols can be realized, border dynamics can be monitored in real time, and national security can be ensured.

This solution focuses on gasoline-electric hybrid power, ultra-long battery life and professional inspection functions, providing reliable solutions for various inspection tasks. If you have any adjustment needs for the technical parameters and functional modules in the solution, or want to add details of specific application scenarios, please feel free to tell me.
